HB-40507 H-Shaped Barndominium Plan: All Five Bedrooms In One Quiet Wing
3,000–3,999 sq ft · 5 bed / 3 bath · 1 story
PDF plan set $1,349.99 · Five printed sets $1,599.99
HB-40507 takes the cleanest possible split: every bedroom in one wing, every shared room in the other, and an enclosed entry hub in between with covered porches on both sides of it.
Layout
- Center: An enclosed entry and foyer hub, with covered front and rear porches on either side of it.
- Left Wing: Open living, dining and kitchen, with the pantry and laundry next to the kitchen and a large side porch.
- Right Wing: Four secondary bedrooms and the primary suite.
Who It Suits
Families who want the living side completely free of bedroom doors, so late nights in the kitchen do not wake anyone.
Plan Specs
| Heated Area | 3,000–3,999 sq ft |
|---|---|
| Bedrooms | 5 |
| Bathrooms | 3 |
| Stories | 1 |
| Footprint | See the floor plan |
| Garage | None (pair with a detached garage or shop) |
| Shape | True H: connector in the middle, courtyard front and back |
| PDF Plan Set (Single Build) | $1,349.99 |
| Five Printed Sets | $1,599.99 |
What It Costs To Build
At a standard finish of $80–$120 per square foot of heated space, 3,000–3,999 sq ft comes to about $240,000 – $479,880. A high-end finish at $150 or more per square foot starts around $450,000. Land, site work, septic and utilities are extra, and porches price closer to shell rates.
An H has much more exterior wall than a rectangle of the same size, so plan toward the top of the range. How the H shape affects cost.
Lot Width Needed
The overall footprint for this plan is shown on the floor plan drawing. Add your county's side setbacks to both sides of that width; on rural parcels they commonly run 10 to 25 feet a side.
Get The HB-40507 Plan Set
Plan sets include the cover sheet, floor plan, elevations, sections, foundation, roof plan and MEP sheets. The designer quotes modifications, such as an extra bath, an attached garage or a mirrored layout, within about 72 hours.
