HB-40509
HB-40509 H-Shaped Barndominium Plan: A Porch-Lined Courtyard You Walk Through To The Door
3,000–3,999 sq ft · 4 bed / 3 bath · 1 story · 72' × 60'
PDF plan set $1,349.99 · Five printed sets $1,599.99
HB-40509 is the courtyard plan. Its 28-foot living room sits toward the back, so the front court is deep, and covered porch lines both sides of it before ending in two small screened porches.
Layout
- Center: A 28-foot living room with glass double doors straight onto the front court.
- Left Wing: A 21-foot kitchen and dining room at the back, the primary suite at the front.
- Right Wing: Three bedrooms, two baths and a 21' × 16' game and media room at the front, so its noise carries toward the yard.
- Courtyard: Covered porch down both sides, ending in two screened porches.
Who It Suits
People who will actually live in the courtyard: morning coffee, evening meals, a place for kids to play within sight of the living room.
Plan Specs
| Heated Area | 3,000–3,999 sq ft |
|---|---|
| Bedrooms | 4 |
| Bathrooms | 3 |
| Stories | 1 |
| Footprint | 72' wide × 60' deep |
| Garage | None (pair with a detached garage or shop) |
| Shape | True H: connector in the middle, courtyard front and back |
| PDF Plan Set (Single Build) | $1,349.99 |
| Five Printed Sets | $1,599.99 |
What It Costs To Build
At a standard finish of $80–$120 per square foot of heated space, 3,000–3,999 sq ft comes to about $240,000 – $479,880. A high-end finish at $150 or more per square foot starts around $450,000. Land, site work, septic and utilities are extra, and porches price closer to shell rates.
An H has much more exterior wall than a rectangle of the same size, so plan toward the top of the range. How the H shape affects cost.
Lot Width Needed
About 100–110 feet of buildable width once typical side setbacks are added. Setbacks vary widely by county, so confirm yours before you buy a plan.
Get The HB-40509 Plan Set
Plan sets include the cover sheet, floor plan, elevations, sections, foundation, roof plan and MEP sheets. The designer quotes modifications, such as an extra bath, an attached garage or a mirrored layout, within about 72 hours.
